Spartherm Linear Corner 46x46x50 RLA

Spartherm Stove - Linear Corner 46x46x50 RLA

Flexible 2-sided corner wood fire.

2-sided fire with substantial fire view

The Linear Corner 46x46x50 RLA wood fire has glass on two sides, allowing for flexibility of installation, and is equipped with a unique, patented elevating door system.  As a compact fire, it is suitable for smaller living spaces where there are limited options for flue installation.  You can select from left or right facing variants.

Spartherm Stove - Linear Corner 46x46x50 RLA Specifications

Series Linear
Category Wood fires
Energy efficiency class A+
Model Built-in
Fire view 2-sided
Shape Square
Fuel Wood
Combustion system Combustion air from living area
Door type Elevating door with fixed handle
Control Manual control
Colours Black
Material Steel
Interior White chamotte, Black chamotte
Output net min.  (kW) 4.9
Output net max.  (kW) 9.1
Efficiency (%) 80.0
Consumption wood max (kg/h) 2.2
NOx emission (mg/Nm3-13% O2) 200
Built-in depth (mm) 515
Weight (kg) 145
Flue rear (mm) 180
External air connection Base
Convection connection
230V necessary
Approvals EN13229
